Elkay  |  SKU: EZWS-ERPBM28K

Elkay EZWS-ERPBM28K | SwirlFlo In-wall Bi-Level Bottle Filler l Filterless, Refrigerated, Stainless Steel (comes with a Mounting Frame)

$ 6,716.99

Shipping

🚚✨ Free Shipping in the Continental U.S.
All Products. No Minimums.


Estimated Shipping Times:


Important Note on Delivery Times

All shipping estimates provided are approximate only. While we always strive to meet or exceed your delivery expectations, we cannot guarantee the exact delivery times listed.

For time-sensitive orders, please contact us directly so we can provide a more accurate lead time estimate based on your specific requirements.

Same Day Shipping

All in stock orders received before 3PM EST will ship the same day. Orders received after 3PM EST will ship the following business day.

Water Filters, Hand Dryers, & Indoor Bottle Fillers are our most popular in stock items.

Outdoor Tubular Drinking Fountains

Evergreen normally ships in 5-15 days. Black, Gray and Blue ship in 2-4 weeks.

Ice Machines

In stock units ship within 48 hours. Other units normally ship in 2-4 weeks.

Other

Orders that ship directly from a manufacturer normally have a firm shipping estimate but those dates are subject to change due to manufacturer production, inventory or shipping. We do our best to estimate ship dates but orders shipping directly from the manufacturer can have unexpected delays. We will confirm tracking information when orders ship directly from a manufacturer but may not have updates or estimates beyond the original estimate. Once your order is placed with the manufacturer, it may not be able to be cancelled even if it hasn't shipped yet.

Please contact support@bottlefillingstations.com to confirm delivery time for a specific product or quantity. Or to inquire about an existing order.


Special Case Shipping Rates



Please note that shipping rates are subject to change at any time.  We reserve the right to charge an additional fee in addition to the regularly advertised shipping fee for shipping to remote areas not easily accessible by typical freight carrier means (i.e. islands only accessible by ferry). If your order falls into this category, you will be notified upon receipt of your order, and have the option to complete the purchase with additional fee or to cancel the order.  Please note, these instances are very rare, as most locations are reachable by regular freight. If you have any questions, please contact us!


Key Terms & Conditions



Exceptions may apply to islands and other remote territories.

All orders shipped by the carrier of our choice.














The Elkay EZWS‑ERPBM28K is a bi‑level ezH2O® bottle filling station with integral SwirlFlo® fountains, built for high‑traffic indoor environments. This stainless steel, refrigerated, non‑filtered unit delivers up to 8.0 gallons per hour of chilled drinking water with ADA‑compliant design and sustainability features.


Key Specifications:

Design Bi‑level bottle filling station with integral SwirlFlo® fountains
Finish Stainless Steel
Filtration Non‑filtered; filtered version available as LZWS‑ERPBM28K
Refrigeration 8.0 GPH of 50°F chilled water, 115V/60Hz, 370W
Stations Served Bi‑level, 2 drinking fountains & 1 bottle filler


Features & Benefits:

  • Hands‑Free Bottle Filling: Electronic sensor activation for hygienic use
  • Flexi‑Guard® Bubbler: Mechanical push button for reliable water access
  • Antimicrobial Protection: Silver ion components keep surfaces cleaner
  • Green Ticker™: Displays bottles saved from waste
  • Real Drain System: Eliminates standing water for improved sanitation


What's Included:

  • EZWS‑ERPBM28K Bottle Filling Station with Bi‑Level SwirlFlo® Fountains
  • Mounting Frame (MFWS210)
  • Chiller (ECH8)
  • Installation instructions and warranty documentation


Comparison With Other Bottle Filling Station Models:

EZWS‑ERPBM28K LZWS‑EDFP217K LZSTL8WSLK
Finish Stainless Steel Stainless Steel Light Gray Granite
Filtration Non‑filtered 51300C WaterSentry® Plus Filter, 3,000 gal 51300C WaterSentry® Plus Filter, 3,000 gal
Features Bi‑level In-wall refrigerated fountain, mechanical bubbler Soft Sides®in-wall fountain, non‑refrigerated, Flexi‑Guard® bubbler Bi‑level on wall ADA cooler, refrigerated 8.0 GPH, Flexi‑Guard® bubbler


FAQ


Q: Does the Elkay EZWS‑ERPBM28K Include Filtration?
A: No. It’s a non‑filtered model. For filtered applications, choose the LZWS‑ERPBM28K or add the EWF3000 Filter Kit.

Q: What Is the Required Installation Depth?
A: Installation requires a minimum of 12" wall depth to accommodate the recessed mounting frame and chiller.

Q: Is the Elkay EZWS‑ERPBM28K ADA Compliant?
A: Yes. The EZWS‑ERPBM28K meets ADA and ICC A117.1 accessibility requirements when installed properly.

Q: What Accessories are Available for Elkay EZWS‑ERPBM28K?
A: Options include the LKAPR1 SwirlFlo® Cane Apron and the ACCESS12X38‑5 Access Panel.

Q: What Is the Elkay EZWS‑ERPBM28K Warranty Coverage?
A: Elkay provides a 5‑year limited warranty on the refrigeration system and a 1‑year warranty on electrical and water system components.

Q: What Maintenance Is Required for Elkay EZWS‑ERPBM28K?
A: Routine cleaning of exterior surfaces, checking for leaks, and filter replacement if upgraded with the EWF3000 kit. The Green Ticker™ and LED indicators help track usage and filter status.


NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
