Elkay  |  SKU: EBWDCM0SSC-BD

Elkay EBWDCM0SSC-BD | Liv EZ Water Dispenser | Non-Refrigerated, Stainless Steel

$ 1,287.60
Shipping calculated at checkout.

Product Care Information

Installation

To install your Elkay LIV EZ Built-in Filtered Water Dispenser, ensure you have a water line available. A qualified plumber should perform the installation if you're unsure about making these connections.

  • Cut a wall opening measuring 19-1/2"H x 14-1/2"W at approximately 59-2/5" from the floor.
  • Verify the wall cavity depth is at least 3-1/2" (89 mm) to accommodate the unit.
  • Route the 3/8" water line through the opening at the base of the dispenser.
  • Level the unit and secure it to wall studs using 4 screws (not included).
  • Install the 3 AA batteries in the battery compartment.
  • Insert the filter into the filter head and turn clockwise to lock in place.
  • Connect the water line to the shutoff valve at the filter's inlet.
  • Open the water supply and check for leaks.
  • Flush the system by dispensing at least one gallon of water before regular use.
  • Attach the glass front cover using the included Phillips head screws.



Maintenance

To keep your Elkay LIV EZ in optimal condition:

  • Replace the filter and batteries annually.
  • Monitor the filter status light - pulsing red indicates 91.6% capacity used, solid red means immediate replacement needed.
  • Remove the front panel screws when replacing the filter.
  • Turn off the water supply before filter replacement.
  • Rotate old filter counterclockwise to remove it.
  • Install new filter by turning clockwise until locked.
  • Turn water supply back on after filter replacement.
  • Press the reset button above the battery compartment to reset the filter light.
  • Maintain water pressure between 40-105 psi (60 psi optimal).
  • Regularly check for leaks around connections.
  • Clean exterior with mild detergent and soft cloth as needed.



Refer to the product manual for detailed installation and maintenance information.

The Elkay EBWDCM0SSC-BD Series delivers ambient water through a mechanically-activated, commercial-grade dispenser with laminar flow technology.



Key Specifications:

  • Water Type: Ambient (Non-Refrigerated)
  • Activation: Mechanical Button
  • Dimensions: 5-1/8" x 18" x 28"
  • Installation: Built-in, Indoor + Outdoor



Features & Benefits:

  • Sustainable Hydration: Eliminates the need for expensive disposable bottled water, reducing plastic waste and storage space requirements in commercial environments.
  • No Power Required: The EBWDCM0SSC-BD operates mechanically without electrical connections, ensuring continuous water access during power outages and reducing energy costs.
  • Versatile Installation: Fits within standard two-stud wall spacing with optional drain connection, making it ideal for lobbies, conference rooms, and classrooms.
  • Clean, Splash-Free Fill: Laminar flow technology provides a smooth water stream that minimizes splashing while filling bottles quickly and efficiently.



FAQ



Q: Does the EBWDCM0SSC-BD require electricity to operate?

A: No, this unit is completely mechanical and requires no electrical connection. It operates through a mechanical button activation system, making it ideal for locations where power access is limited or during service disruptions.

Q: Can this water dispenser be installed outdoors?

A: Yes, the EBWDCM0SSC-BD is rated for both indoor and outdoor installation. However, when used in non-temperature controlled environments, the unit must be adequately winterized and protected from extreme heat to prevent damage in harsh climates.

Q: Does this model include water filtration or refrigeration?

A: This model dispenses ambient, non-filtered water. However, optional accessories are available including a Universal Filtration Kit (EWF3000) with 3000-Gallon capacity and a Remote Chiller (ER101Y) for refrigerated water at 10 GPH cooling capacity.



Detailed Features & Benefits



Mechanical Reliability & Service Continuity: The EBWDCM0SSC-BD utilizes a mechanical bottle filler button that ensures uninterrupted water access regardless of electrical service disruptions. This makes it an exceptionally reliable choice for high-traffic commercial settings, emergency preparedness applications, and facilities where consistent water access is critical. The simple mechanical design also reduces maintenance requirements and eliminates concerns about electronic component failures.

Space-Efficient Built-In Design: Engineered to fit within the width and depth of two standard wall studs, this water dispenser maximizes floor space while providing full functionality. The compact 5-1/8" depth allows for seamless integration into walls near water lines, creating a clean, professional appearance in lobbies, conference rooms, and public spaces. The included brass drain can be installed vertically through the bottom of the enclosure for easy connection to a P-trap, or the unit can operate without a drain connection depending on installation requirements.

Commercial-Grade Stainless Steel Construction: The EBWDCM0SSC-BD features durable stainless steel construction that withstands heavy use in commercial and hospitality environments. This material choice ensures longevity, maintains a professional aesthetic, and provides resistance to corrosion and wear. The laminar flow delivery system incorporated into the dispenser creates a smooth, aerated water stream that fills bottles cleanly with minimal splashing, enhancing user experience while maintaining cleanliness around the dispensing area.



NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
