Elkay LZ8WSSSMC | EZH2O Surface Mount Bottle Filling Station | Filt...
The Elkay LZ8WSSSMC EZH2O® Refrigerated Surface Mount Bottle Filler combines functionality, sustainability, and user‑friendly design to provide a superior hydration solution for indoor environments. Its slim profile and touchless operation make it an excellent choice for schools, offices, gyms, and other commercial spaces.
Key Specifications:
| Design | Surface‑mounted refrigerated bottle filling station with reduced 12" wall projection |
| Finish | Stainless steel construction with removable grate for easy cleaning |
| Filtration | Includes 51300C WaterSentry® Plus Filter, NSF 42/53 certified, 3,000‑gallon capacity |
| Refrigeration | Provides 8.0 GPH of 50°F chilled water, tested to ASHRAE 18 standards |
| Stations Served | 1 station (bottle filler only, no fountain) |
Features & Benefits:
- Hygiene First: Touchless sensor activation with Real Drain™ system to eliminate standing water.
- Sustainability: Green Ticker™ displays bottles saved, reducing single‑use plastic waste.
- Space‑Saving: Slim profile design ideal for shallow walls and tight spaces.
- Low Maintenance: Front‑access filter replacement with LED visual monitor.
- Reliable Cooling: Consistent chilled water output for busy environments.
What's Included:
- LZ8WSSSMC Bottle Filling Station
- Wall mounting plate and hardware
- WaterSentry® Plus filter cartridge
Comparison of Surface Mount Bottle Fillers:
| Feature | LZ8WSSSMC | LZSTL8WSLK | LZ8WSBPRO |
|---|---|---|---|
| Finish | Stainless Steel | Light Gray Granite | Stainless Steel |
| Filtration | Filtered (3,000 gal, 51300C included) | Filtered (3,000 gal, 51300C included) | Pro Filtration (PFAS/PFOA/PFOS reduction) |
| Best For | Indoor environments with shallow walls or compact spaces needing a single bottle filler | High‑traffic indoor environments such as schools, gyms, and offices needing dual access hydration | Facilities requiring advanced filtration performance in offices, healthcare, and public spaces |
| Features | Touchless sensor, Real Drain™, slim profile | Bi‑level cooler + bottle filler, Green Ticker™, ADA compliant | Wall‑mount bottle filler, Pro Filtration, ADA compliant |
| Activation | Electronic sensor (touchless) | Electronic sensor + pushbar bubblers | Electronic sensor (touchless) |
How to Install the LZ8WSSSMC:
- Mount the hanger bracket securely to the wall using all required fasteners.
- Hang the cooler onto the bracket and lock it in place.
- Connect water supply with a dielectric coupling and attach the drain trap.
- Install the bottle filler and filter (for LZ models) following the supplied instructions.
- Plug into a dedicated GFCI outlet and flush the system to check for leaks.
How to Maintain the LZ8WSSSMC:
- Replace the 51300C filter annually or when the LED turns red.
- Reset the filter monitor after each replacement using the programming button.
- Clean stainless surfaces with mild soap or glass cleaner; avoid abrasives.
- Inspect drains and tubing for leaks or clogs during routine checks.
- Test sensor and cooling regularly to ensure proper dispensing and chilled output.
FAQ
Q: How Often Should the LZ8WSSSMC Filter Be Replaced?
A: Replace when the LED indicator turns red, typically after 3,000 gallons or 12 months, whichever comes first.
Q: Is the LZ8WSSSMC Suitable for Outdoor Installation?
A: No. The LZ8WSSSMC is designed for indoor use only and should not be installed outdoors or in humid environments.
Q: What Is the Water Flow Rate of the LZ8WSSSMC?
A: The fill rate is 1.1 GPM, providing a clean fill with minimal splash.
Q: Does the LZ8WSSSMC Require a Dedicated Electrical Circuit?
A: Yes. It is recommended to install the unit on a dedicated 20A circuit for optimal performance.
Q: What Warranty Coverage Is Provided With the LZ8WSSSMC?
A: Elkay provides a 5‑year limited warranty on the refrigeration system and a 12‑month warranty on electrical components and the water system.
Q: What Filter Does the LZ8WSSSMC Use? Is a Filter Included?
A: The LZ8WSSSMC uses the Elkay 51300C WaterSentry® Plus Filter. One filter cartridge is included with purchase.
Q: What Environments Are Best Suited for the LZ8WSSSMC?
A: The LZ8WSSSMC is best for schools, offices, gyms, and other commercial indoor spaces needing compact, hygienic hydration.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
"Hydrate Everyone, Everywhere!" BottleFillingStations.com | Contact us now
- Remove the front cover of the Elkay LZ8WSSSMC by loosening the two 5/16" hex screws on the underside of the cooler.
- Detach the hanger bracket and secure it to the wall using five screws in 7/16" diameter mounting holes; add a support carrier if wall strength is insufficient.
- Hang the Elkay LZ8WSSSMC onto the bracket and fasten with two additional mounting screws to secure the frame to the wall.
- Connect the 3/8" O.D. copper water supply line to the shut‑off valve; ensure supply pressure is between 20–105 psi (filtered Elkay LZ8WSSSMC units require minimum 40 psi).
- Install the waste outlet using 1‑1/4" drain pipe extending 2" from the wall; connect to a P‑trap provided by installer.
- Maintain at least 6" clearance from cabinet louvers to wall for ventilation; install on a grounded 115V, 60Hz, 20A GFCI‑protected circuit.
- Mount the bottle filler: remove the top cover, secure the wall plate above the basin with six 7/16" screws, then set the filler onto the basin and attach to angled tabs on the plate.
- Feed the power cord and 3/8" water line through the basin and cooler, then connect internally to the Elkay LZ8WSSSMC cooler fittings.
- Install the filter cartridge (filtered Elkay LZ8WSSSMC units only): remove protective cap, mark installation date, and insert firmly into the filter head with label facing outward.
- For detailed steps, refer to the installation manual provided in the package or contact a licensed plumber/electrician.
- Inspect all drain and water connections on the Elkay LZ8WSSSMC regularly for leaks; tighten or reseal as needed.
- Replace the filter annually or when the LED indicator shows red; reset the filter monitor after replacement.
- Flush at least two gallons of water after filter changes to purge air and carbon particles.
- Clean exterior panels of the Elkay LZ8WSSSMC with mild soap and water; avoid harsh chemicals or abrasives that may damage the finish.
- Check the sensor operation and bottle counter display; reset bottle count if required through the programming menu.
- Verify water pressure remains within the recommended range for consistent performance.
- Disconnect power before servicing internal components of the Elkay LZ8WSSSMC to avoid electrical hazards.
- For service or repairs, consult the manual or a certified service representative.
