Zurn ZEMS6003AV-WS1-IS | AquaVantage ZEMS Exposed Hardwired Sensor ...
The ZEMS6003AV-WS1-IS is a hardwired, sensor-activated flush valve designed for urinals requiring 1.0 gallons per flush. Built with Zurn’s AquaVantage® diaphragm technology and a vandal-resistant actuator, it delivers reliable performance in high-traffic commercial restrooms while supporting water conservation goals.
Key Specifications:
- Flow Rate: 1.0 gallons per flush (Water Saver).
- Operation: Infrared sensor activation with capacitive manual override button.
- Construction: Chrome-plated brass valve body with chloramine-resistant seals.
- Dimensions: 11-1/2" valve height; top spud connection.
Features & Benefits:
- Water-Saving Performance: The 1.0 gpf flush volume balances conservation with effective fixture evacuation. Ideal for facilities upgrading from standard 1.5 gpf systems.
- Touchless Hygiene: The integral sensor provides hands-free operation, reducing the spread of germs. Manual override button allows maintenance flushing without removing the actuator.
- Durable Design: Dezincification-resistant brass body, reinforced diaphragm, and vandal-resistant stop cover ensure long-term reliability in public environments.
What's Included:
- 1 x ZEMS6003AV-WS1-IS Exposed Urinal Flush Valve
- 1 x Sensor-Activated Actuator Assembly with Manual Override
- 1 x High Back Pressure Vacuum Breaker with One-Piece Hex Coupling Nut
- 1 x Adjustable Tailpiece
- 1 x Spud Coupling and Flange for Top Spud Connection
- 1 x Sweat Solder Kit
- 1 x Cast Wall Flange with Set Screw
- 1 x Vandal-Resistant Stop Cover
- 1 x Installation Hardware
Options Available:
- ZEMS6003AV-ULF-IS: Ultra Low Flow model with 0.125 gpf for maximum water savings
- ZEMS6003AV-IS-EWS: Extra Water Saver model with 0.5 gpf and hardwired sensor activation
FAQ
Q: Is this valve compatible with all urinals?
A: The ZEMS6003AV-WS1-IS is designed for 3/4" top spud urinals rated for 1.0 gpf. Always verify fixture compatibility before installation.
Q: What power source is required?
A: This valve must be powered by Zurn’s HW6 hardwire power converter or PC6 plug-in converter. Using non-Zurn power supplies may result in malfunction or damage to the sensor system.
Detailed Features & Benefits
Sensor Precision: The infrared convergence sensor minimizes false activations and supports adjustable range settings. Ideal for restrooms with varying stall configurations.
Commercial Durability: Engineered for high-use environments, the valve includes a vandal-resistant stop cap, cast wall flange, and chloramine-resistant internal seals.
Water Efficiency: The WS1 model supports LEED credits and WaterSense compliance when paired with compatible fixtures, offering a balance between conservation and performance.
NOTICE: All products come with a limited three-year warranty on materials and workmanship when properly installed and maintained. Decorative finishes warranted for one year.
"Hydrate Everyone, Everywhere!" BottleFillingStations.com | Contact us now
- All plumbing is to be installed according to state and local codes and regulations.
- Water supply lines need to allow proper water flow for each fixture.
- Flush all lines of any debris before making connections.
- Do not use pipe sealant or plumbing grease on any fitting other then the control stop inlet.
