Elkay  |  SKU: LZWS-LRPBM8K

Elkay LZWS-LRPBM8K | In-wall Filtered Bottle Filler with Swirlflo Fountain

$ 4,413.00
Shipping calculated at checkout.
In Stock
Free Shipping
_____________________________________
_____________________________________

Product Care Information
Installation

  • Elkay Bottle Filling Stations require installation from a licensed plumber. Email us at support@bottlefillingstations.com, and we can see if our network of of service professionals cover your area.
  • Requires access to electrical connection.
  • Product also includes physical copy of installation instructions in package.

Maintenance

Cleaning

It is recommended to routinely clean your Bottle Filling Station with a soft cloth and mild dishwashing soap to spray and wipe down the unit.  It is also recommended to clean the flexible fill mat.  Remove the four screws to wipe beneath and on top of the mat.



Video on Cleaning



Video on Fil Mat

Filter Replacement

When filter status light turns to red, the filter needs to be changed.  Here are some detailed instructions.

Video on Filter Change

Requires a minimum of 12" of wall depth for installation.

One of the most popular models, the Elkay LZWS-LRPBM8K In-Wall Water Bottle Filling Station makes drinking water more practical, safe, and appealing than ever before.

  • ADA compliant design
  • Fully Recessed In-wall design
  • Sanitary bottle fill created from hands-free sensor activation and recessed spout with 20 second auto shut-off system.
  • Green Ticker™ tracks number of plastic bottles saved from waste.
  • Ships in 5-7 business days.

VIEW SPEC SHEET HERE: Elkay LZWS-LRPBM8K

FILTERED?

Yes

COOLER CABINET FINISH

Stainless Steel

POWER

115V/60Hz

BUBBLER OPTION

FlexiGuard Saefty Bubblrt

MOUNTING DETAILS

Wall Mount (In-Wall Frame/Plate)

CHILLING DETAILS

8 GPH

INSTALLATION LOCATION

INDOOR

DIMENSIONS

L: 19-3/4″

W: 19″

H: 55-1/8″

SHIPPING WEIGHT

173 lbs

Elkay LZWS-LRPBM8K

PRODUCT COMPLIANCE
  • GreenSpec
  • ADA Compliant
  • CAN/CSA 22.2 120
  • ASME A112.19.3/CSA B45.4
  • Buy American Act
  • UL 399
  • NSF 61
  • NSF 42
  • NSF 53
  • NSF 372 (no lead)

Warranty

Refrigeration System (IF APPLICABLE)

Elkay LZWS-LRPBM8K refrigeration system includes 5 year limited warranty.

Electrical Parts & Water System

Elkay LZWS-LRPBM8K warranty for electrical parts and water system is valid 18 months from the factory shipment or 12 months from the date of installation. The warranty will honor which ever date falls first.  View more warranty details here.

Installation Notes

  • Elkay LZWS-LRPBM8K requires installation from licensed plumber. Email us at support@bottlefillingstations.com to be connected to our network of Bottle Filler installation professionals.
  • Requires access to electrical connection.
  • Product also includes physical copy of installation instructions in package.
  • View detailed Elkay LZWS-LRPBM8K INSTALLATION INSTRUCTIONS.

Maintenance

Cleaning

It is recommended to use soft cloth and mild dishwashing soap to spray and wipe down the unit.  Routine cleaning is also suggested.

Filter Replacement (IF APPLICABLE)

When filter status light turns to red, the filter needs to be changed.  Follow these steps:

1) Remove the bottom access panel.

2) Unplug unit

3) Unscrew old filter

4) Install new WaterSentry Plus filter.

5) Reset filter light back to green by removing top cover and pressing the black reset button.  Select reset filter.  The light should appear as green.  Detailed instructions on filter light reset are included in produce package.

View VIDEO of CLEANING, FILTER REPLACEMENT, & FILTER LIGHT RESET instructions.

FAQ

Q: How do I access the filter status and bottle counter button?

A: To access the program button, the lower panel of the unit must be must be opened. The programming button is located at the bottom right corner of the upper panel. This area of the unit is concealed by the lower panel.

Q: Does this model come with a Mounting Frame?

A:  Yes, this model comes with an MLP100 In-wall Carrier Mounting Frame.

*MADE IN THE UNITED STATES.

Experience the benefits of the very popular Elkay LZWS-LRPBM8K Water Bottle Filling Station. Best Support, Fast Shipping, & Low Prices. CONTACT US NOW!

DOWNLOADS

SPEC SHEET MANUAL
WARRANTY
