Elkay LZWS-EDFPBM117K | In-wall Bi-level Bottle Filling Station | ...
The Elkay LZWS-EDFPBM117K ezH2O® Bottle Filling Station combines a filtered bottle filler with a bi-level integral SwirlFlo® drinking fountain in a space-saving in-wall design. Ideal for indoor applications, this non-refrigerated hydration station features hands-free bottle filling, a Visual Filter Monitor, Green Ticker™, Real Drain System, and durable stainless steel construction.
Key Specifications:
| Design | ezH2O® Bottle Filling Station with Bi-Level Integral SwirlFlo® Fountain |
| Finish | Stainless Steel |
| Filtration | Includes 51300C WaterSentry® Plus Filter, certified to NSF/ANSI 42, 53, 372, and 401 for reduction of lead, microplastics, Class 1 particulates, cysts, and chlorine taste and odor. |
| Refrigeration | Non-Refrigerated. For refrigerated option, chose the Elkay LZWS-LRPBM28K |
| Stations Served | 2 (Bi-level fountains + bottle filler) |
Features & Benefits:
- Hands-Free Bottle Filling: Electronic sensor activation allows touch-free bottle filling.
- Visual Filter Monitor: LED filter status indicator alerts users when filter replacement is necessary.
- Green Ticker™: Displays the number of 20 oz. plastic bottles saved from waste.
- Real Drain System: Eliminates standing water from the bottle filling area.
- Antimicrobial Protection: Key plastic components are manufactured with silver ion antimicrobial agents to help provide cleaner, stain- and odor-free surfaces.
What's Included:
- EDFPBM117WS-F Fountain with Integral Bottle Filling Station
- MFWS200 Mounting Frame
- 51300C WaterSentry® Plus Filter
FAQ
Q: How Often Should the Filter Be Replaced in the Elkay LZWS-EDFPBM117K?
A: The Elkay LZWS-EDFPBM117K includes a 51300C WaterSentry® Plus Filter with a 3,000-gallon capacity or up to one year after installation, whichever occurs first.
Q: Is the Elkay LZWS-EDFPBM117K ADA Compliant?
A: Yes. The Elkay LZWS-EDFPBM117K complies with ADA and ICC A117.1 accessibility requirements when installed according to the applicable standards.
Q: Does the Elkay LZWS-EDFPBM117K Bottle Filler Operate Hands-Free?
A: Yes. The Elkay LZWS-EDFPBM117K features an electronic sensor-activated bottle filler for touch-free operation, while the drinking fountains utilize mechanical front bubbler buttons.
Q: How Does the Visual Filter Monitor on the Elkay LZWS-EDFPBM117K Work?
A: The Elkay LZWS-EDFPBM117K includes a Visual Filter Monitor with an LED status indicator that alerts users when filter replacement is necessary.
Q: Can the Elkay LZWS-EDFPBM117K Continue Operating During Service Disruptions?
A: Yes. The mechanically activated fountain on the Elkay LZWS-EDFPBM117K continues supplying water during service disruptions.
Q: Can the Elkay LZWS-EDFPBM117K Be Installed Outdoors?
A: No. The Elkay LZWS-EDFPBM117K is designed for indoor applications only.
Q: What Accessories Are Available for the LZWS-EDFPBM117K?
A: Optional accessories include the LKAPR1 Cane Apron for SwirlFlo® models and the ACCESS12X38-5 Stainless Steel Access Panel. The access panel is recommended for installations where rear access is not available.
Q: What Makes the Elkay LZWS-EDFPBM117K Unique?
A: The Elkay LZWS-EDFPBM117K combines a bi-level SwirlFlo® drinking fountain with a filtered ezH2O® bottle filling station in a single in-wall unit, providing both bottle filling and drinking fountain access while serving two stations.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
"Hydrate Everyone, Everywhere!" BottleFillingStations.com | Contact us now
The Elkay LZWS‑EDFPBM117K is a filtered, refrigerated bottle filling station paired with a bi-level SwirlFlo® drinking fountain. Designed for schools, offices, healthcare facilities, and other commercial environments, it provides touchless bottle filling, chilled drinking water, and integrated filtration in a space-saving in-wall configuration.
Key Installation Requirements:
- In-wall installation with proper framing and carrier support
- Cold water line only (40–100°F operating temperature)
- Electrical supply: 115V / 60Hz grounded outlet with GFCI protection
- Drain connection required for fountain basin operation
- Maintain clearance for filter replacement and refrigeration service
- Follow ADA guidelines for installation height and accessibility
Important Notes Before Installing:
- Do not connect to hot water lines
- Always depressurize the water line before servicing or replacing the filter
- Use only genuine Elkay replacement filters to maintain certified filtration performance
- Ensure the bottle filler sensor area remains unobstructed for reliable activation
- Provide adequate ventilation clearance around refrigeration components
- Verify wall cavity dimensions and rough-in requirements before installation
Basic Installation Overview:
- Prepare the wall opening and install the required framing support
- Secure the carrier assembly according to manufacturer specifications
- Connect the cold water supply line and flush plumbing thoroughly
- Install the filter head and filter cartridge assembly
- Connect the fountain drain line to the building drainage system
- Mount the fountain and bottle filler assembly to the carrier
- Connect electrical power to a grounded outlet
- Pressurize the system and inspect all water connections for leaks
- Test bottle filler activation, water flow, and cooling performance
For complete specifications and installation guidelines, download the official LZWS‑EDFPBM117K Spec Sheet and the Installation Manual.
