Elkay LK4430BF1LFRK | Freestanding Tri-level Bottle Filling Station | Filterless, Non-refrigerated
Elkay LK4430BF1LFRK | Freestanding Tri-level Bottle Filling Station | Filterless, Non-refrigerated - Evergreen is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Care Information
Product Care Information
Installation
- Elkay & Halsey Taylor Bottle Filling Stations require installation from a licensed plumber. Email us at support@bottlefillingstations.com, and we can see if our network of service professionals cover your area.
- Requires access to electrical connection.
- Product also includes physical copy of installation instructions in package.
ezH2O Installation Video:
Maintenance
It is recommended to routinely clean your Bottle Filling Station with a soft cloth and mild dishwashing soap to spray and wipe down the unit. It is also recommended to clean the flexible fill mat. Remove the four screws to wipe beneath and on top of the mat.
ezH2O Maintenance Video:Filter Replacement
When filter status light turns to red, the filter needs to be changed. Here are some detailed instructions.
ezH20 Filter Change Video:
Elkay LK4430BF1LFRK | Freestanding Tri-level Bottle Filling Station...
*PLEASE NOTE: Colors besides Evergreen, Black, Blue, & Gray require a minimum order quantity of 10 units. Contact us for more details.
An industry-leading Outdoor Drinking Fountain, the Elkay LK4430BF1LFRK Outdoor Water Bottle Filling Station makes drinking water more practical, safe, and appealing than ever before.
- ADA compliant design
- Two drinking fountains and a bottle filler
- Quick fill rate of 1 Gallon Per Minute
- Corrosion protection from E-Coat immersion process coat
- Vandal-resistant bubbler and pushbutton
- Freeze-resistant valve
Elkay LK4430BF1LFRK Resources:
- Elkay LK4430BF1LFRK Spec sheet
- Elkay LK4430BF1LFRK Installation manual
- Elkay LK4430BF1LFRK CAD symbols: FRONT - TOP - SIDE
- Elkay LK4430BF1LFRK BIM file (RFA)
|
FILTERED? |
No |
|
COOLER CABINET FINISH |
12 color options |
|
POWER |
No Electrical Required |
|
BUBBLER OPTION |
Vandal-Resistant |
|
MOUNTING DETAILS |
Floor Mount/Freestanding |
|
CHILLING DETAILS |
Non-Refrigerated GPH |
|
INSTALLATION LOCATION |
Outdoor |
|
DIMENSIONS |
L: 14" W: 48" H: 52-1/8" |
|
SHIPPING WEIGHT |
280 lbs |
|
PRODUCT COMPLIANCE |
● ADA & ICC A117.1 ● ASME A112.19.3/CSA B45.4 ● Buy American Act ● GreenSpec ● NSF 61 ● NSF 372 (lead free)
|
Warranty
Electrical Parts & Water System
Elkay LK4430BF1LFRK warranty for electrical parts and water system is valid 18 months from the factory shipment or 12 months from the date of installation. The warranty will honor whichever date falls first. View more warranty details here.
Installation Notes
- Elkay LK4430BF1LFRK requires installation from a licensed plumber. Email us at support@bottlefillingstations.com to be connected to our network of Bottle Filler installation professionals.
- Product also includes a physical copy of installation instructions in the package.
- View detailed Elkay LK4430BF1LFRK MANUAL.
Maintenance
Cleaning
It is recommended to use soft cloth and mild dishwashing soap to spray and wipe down
FAQ
Q: What colors are available for the Outdoor Bottle Filling Stations?
A: Outdoor Bottle Filling Stations come standard in Evergreen, which typically has a lead time of 15-20 business days. See other color options below, which have a lead time of ~ 20-30 business days.
Q: What makes the Outdoor Freeze Resistant Bottle Filler, Freeze Resistant?
A: The valve is designed to be installed 18” below the frost line. In addition, 60” of tubing is provided.
Q: Are filtered versions of Outdoor Bottle Filling Stations available?
A: Unlike Indoor EZH2O Bottle Filling Stations, Outdoor Bottle Fillers don’t come with a filtered option. However, it is quite common to create inline filtration by ordering and properly installing a separate WaterSentry Plus Filter Kit. If this is desired, we will need to create a custom order.
Contact us at support@bottlefillingstations.com or (855) 558-9600.
Q: Are refrigerated versions of Outdoor Bottle Filling Stations available?
A: Outdoor Bottle Fillers do not come with chillers because of the risk presented from outdoor elements, especially in the cold. However, if installed with proper shelter and temperature, a remote chiller can be hooked up to the Bottle Filler, which can especially be beneficial in warmer climates. Please contact us for further details.
Q: Are Outdoor Bottle Filling Stations durable?
A: Yes, Elkay Bottle Filling Stations are very durable. They are made with heavy-duty steel with a textured powder-coat finish and E-coat immersion for year-round protection with minimum maintenance.
*MADE IN THE UNITED STATES.
