Elkay

ERFPM28K

Elkay IN-WALL Kit Bottle Filling Station | ERFPM28K Filterless

MSRP: $4,238.00

Free shipping on all orders over $1500 (mainland US)
Elkay water chillers provide 50 degree drinking water and meet Federal and State low-lead requirements

Requires a minimum of 12" of wall depth for installation.

The ERFPM28K is an in-wall, refrigerated bi-level 'Soft-sides' drinking fountain. This model has a Stainless Steel color finish.

One of the most popular models, theElkay ERFPM28K Water Bottle Filling Station makes drinking water more practical, safe, and appealing than ever before.

The ERFPM28K drinking fountain features a Flexi-Guard bubbler protected by a flexible antimicrobial mouth guard that helps to protect against injury and microorganisms.

Elkay ERFPM28K Spec Sheet HERE

Elkay ERFPM28K Installation manuals:

FILTERED?

No

COOLER CABINET FINISH

Stainless Steel

POWER

115V/60Hz

BUBBLER OPTION

FlexiGuard Safety

MOUNTING DETAILS

Wall Mount (In-Wall Frame/Plate)

CHILLING DETAILS

8 GPH

Elkay ERFPM28K

INSTALLATION LOCATION

INDOOR

NUMBER OF FOUNTAINS

Two fountains

DIMENSIONS

L: 38-1/2″

W: 18-5/8″

H: 40-13/16″

SHIPPING WEIGHT

123 lbs

Elkay ERFPM28K

PRODUCT COMPLIANCE

  • GreenSpec
  • ADA Compliant
  • CAN/CSA 22.2 120
  • ASME A112.19.3/CSA B45.4
  • Buy American Act
  • UL 399
  • NSF 61
  • NSF 372 (no lead)

Warranty

Refrigeration System (IF APPLICABLE)

Elkay ERFPM28K refrigeration system includes 5-year limited warranty.

Electrical Parts & Water System

Elkay ERFPM28K warranty for electrical parts and water system is valid 18 months from the factory shipment or 12 months from the date of installation. The warranty will honor which ever date falls first.  View more warranty details here.

Installation Notes

  • Elkay ERFPM28K requires installation from licensed plumber. Email us at support@bottlefillingstations.com to be connected to our network of Bottle Filler installation professionals.
  • Requires access to electrical connection.
  • Product also includes physical copy of installation instructions in package.
  • View detailed Elkay ERFPM28K INSTALLATION INSTRUCTIONS.

Maintenance

Cleaning

It is recommended to use soft cloth and mild dishwashing soap to spray and wipe down the unit.  Routine cleaning is also suggested.

Filter Replacement (IF APPLICABLE)

When filter status light turns to red, the filter needs to be changed.  Follow these steps:

1) Remove the bottom access panel.

2) Unplug unit

3) Unscrew old filter

4) Install new WaterSentry Plus filter.

5) Reset filter light back to green by removing top cover and pressing the black reset button.  Select reset filter.  The light should appear as green.  Detailed instructions on filter light reset are included in produce package.

View VIDEO of CLEANING, FILTER REPLACEMENT, & FILTER LIGHT RESET instructions.

*MADE IN THE UNITED STATES.
