Zurn ZTR6200-ONE | EcoVantage ZTR Exposed Sensor Piston Water Closet Flush Valve, 1.1 GPF, Chrome
Zurn ZTR6200-ONE | EcoVantage ZTR Exposed Sensor Piston Water Closet Flush Valve, 1.1 GPF, Chrome - Standard is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Care Information
Product Care Information
- All plumbing is to be installed according to state and local codes and regulations.
- Water supply lines need to allow proper water flow for each fixture.
- Flush all lines of any debris before making connections.
- Do not use pipe sealant or plumbing grease on any fitting other then the control stop inlet.
Zurn ZTR6200-ONE | EcoVantage ZTR Exposed Sensor Piston Water Close...
The ZTR6200-ONE is a battery-powered, sensor-operated flush valve designed for water closets with a 1.1 gallon per flush rating. Engineered for low consumption and ADA compliance, it features Zurn’s AquaSense® piston technology, a vandal-resistant metal sensor cap, and a mechanical override button for maintenance flexibility. Ideal for commercial restrooms seeking reliable performance and water savings.
Key Specifications:
- Flow Rate: 1.1 gallons per flush (ONE designation).
- Operation: Sensor-activated flush with mechanical override button (MOB).
- Battery Type: 4 AA alkaline batteries (included).
- Construction: Chrome-plated brass body with chloramine-resistant internal seals.
- Dimensions: 11-1/2" valve height; top spud connection.
Features & Benefits:
- Water-Saving Performance: The 1.1 gpf flush volume supports WaterSense compliance when paired with compatible fixtures.
- Touchless Hygiene: Infrared sensor enables hands-free operation. Manual override button allows flushing during maintenance or sensor recalibration.
- Durable Design: Vandal-resistant metal sensor cap, filtered piston kit, and dezincification-resistant brass body ensure long-term reliability in public environments.
What's Included:
- 1 x ZTR6200-ONE Exposed Closet Flush Valve
- 1 x Sensor Cap Assembly with Manual Override
- 1 x High Back Pressure Vacuum Breaker with One-Piece Hex Coupling Nut
- 1 x Adjustable Tailpiece
- 1 x Spud Coupling and Flange for Top Spud Connection
- 1 x Sweat Solder Kit
- 1 x Cast Wall Flange with Set Screw
- 1 x Installation Hardware
- 4 x AA Batteries (Standard Alkaline)
Options Available:
- ZTR6200-ONE-LL: Long Life battery version with 10-year lithium cell for reduced maintenance
- ZTR6200-ONE-HW: Hardwired version with 7.6 VDC power input for continuous operation
FAQ
Q: Is this valve compatible with all water closets?
A: The ZTR6200-ONE is designed for 1-1/2" top spud water closets rated for 1.1 gpf. Always confirm fixture compatibility before installation.
Q: Can I upgrade to a long-life battery or hardwired power?
A: Yes. The ZTR6200-ONE-LL includes a factory-installed lithium battery rated for up to 10 years. The ZTR6200-ONE-HW is configured for hardwired installations using Zurn’s HW6 power converter.
Detailed Features & Benefits
Sensor Accuracy: Factory-calibrated infrared sensor with courtesy flush and LED indicators. DIP switch settings allow customization for specific restroom layouts.
Water Efficiency: The ONE model supports LEED credits and WaterSense labeling, offering conservation without compromising flush performance.
Maintenance Flexibility: Standard alkaline batteries are included, but facilities may opt for LL or HW variants to reduce service intervals or eliminate battery changes.
NOTICE: All products come with a limited three-year warranty on materials and workmanship when properly installed and maintained. Decorative finishes warranted for one year.
