Zurn Z6000AV-WS1 | AquaVantage Exposed Manual Diaphragm Flush Valve with 1.6 GPF, Chrome
Zurn Z6000AV-WS1 | AquaVantage Exposed Manual Diaphragm Flush Valve with 1.6 GPF, Chrome is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Care Information
Product Care Information
- All plumbing is to be installed according to state and local codes and regulations.
- Water supply lines need to allow proper water flow for each fixture.
- Flush all lines of any debris before making connections.
- Do not use pipe sealant or plumbing grease on any fitting other then the control stop inlet.
Zurn Z6000AV-WS1 | AquaVantage Exposed Manual Diaphragm Flush Valve...
The Zurn Z6000AV-WS1 AquaVantage® Exposed Flush Valve combines superior reliability with water-saving efficiency for commercial restroom environments. Engineered for outstanding performance in high-traffic facilities, this premium flushometer provides consistent operation while helping buildings meet their sustainability goals.
Key Specifications:
- Construction: Chrome-plated brass with proprietary dezincification-resistant low lead alloy.
- Water Pressure: 10-100 psi operating range.
- Connection: Adjustable tailpiece with one-piece hex coupling nut.
- Protection: High back pressure vacuum breaker with internal siphon-guard.
Features & Benefits:
- Water Conservation: Water Saver model operating at 1.6 gallons per flush, balancing performance and water efficiency for standard water closets.
- Triple Filtered By-pass: Advanced filtration system prevents clogging and ensures consistent, reliable performance in demanding environments.
- Vandal Resistance: Includes vandal-resistant stop cap and non-hold-open handle design to withstand abuse in high-traffic settings.
- Complete Installation Package: Includes sweat solder kit with cast wall flange and setscrew for simplified installation right out of the box.
What's Included:
- 1 x Z6000AV Flush Valve body with WS1 (1.6 gpf) flow rate
- 1 x AquaVantage® TPE Diaphragm Assembly
- 1 x High Pressure Vacuum Breaker
- 1 x Adjustable Tailpiece and Coupling Assembly
- 1 x Spud Coupling Assembly
- 1 x Sweat Solder Kit with Cast Wall Flange
- 1 x Vandal-Resistant Stop Cap
FAQ
Q: What's the difference between the AquaVantage® series and standard flush valves?
A: The AquaVantage® series features Zurn's exclusive TPE diaphragm with triple filtered by-pass system for superior clog resistance and reliability. It also includes vandal-resistant components and a complete installation kit with sweat solder connection and cast wall flange as standard features.
Q: Is this model compatible with standard toilet fixtures?
A: Yes, the Z6000AV-WS1 with 1.6 gallons per flush is designed to work with most standard toilet fixtures while offering water conservation benefits. This flow rate provides excellent evacuation performance for commercial applications.
Q: What maintenance is required for this flush valve?
A: Regular maintenance includes annual inspection of the diaphragm assembly and cleaning the control stop filter screen if reduced flow is observed. The triple filtered by-pass and chloramine-resistant materials significantly reduce common maintenance issues, but preventative checks ensure optimal performance.
Detailed Features & Benefits
Premium Diaphragm Technology: The Z6000AV-WS1 features Zurn's exclusive AquaVantage® TPE dual seal diaphragm with a clog-resistant, triple filtered by-pass that provides superior protection against performance issues common in commercial environments. This advanced design prevents debris from affecting operation while resisting the damaging effects of chloramines and other chemicals in the water supply, significantly extending service life.
Water-Saving Performance: The WS1 model delivers reliable performance at 1.6 gallons per flush, meeting standard water efficiency requirements while ensuring proper bowl evacuation. This balanced approach to water conservation helps facilities reduce consumption without sacrificing performance.
Commercial-Grade Construction: Built for demanding conditions of high-traffic restrooms, the Z6000AV-WS1 features a chrome-plated brass body with a polished exterior finish that maintains its appearance through daily use. The proprietary dezincification-resistant low lead brass alloy provides enhanced durability and compliance with drinking water standards. The vandal-resistant design includes a stop cap and non-hold-open handle feature that prevents tampering and water waste, making it ideal for schools, stadiums, restaurants, and other public facilities.
NOTICE: Do not use with water that is microbiologically unsafe or of unknown quality.
