Wilkins 212-ZW209FPGRV | Fire Protection Pressure Reducing Valve, G...
NOTICE: Product images may vary from the actual item due to differences in size or configuration options.
The Wilkins 212-ZW209FPGRV is a pilot-operated pressure reducing valve designed specifically for fire suppression systems to reduce high inlet pressures to safe, stable outlet pressures with grooved end connections and reverse-side pilot configuration.
Key Specifications:
- Size: 2 1/2 Inches
- Maximum Static Pressure: 175 psi
- Temperature Rating: 33°F to 140°F
- Notable Certifications: UL and C-UL Listed
- Connection Type: Grooved Ends, 300 psi
Other Related Variants:
- No other related variants specified
Materials:
- Ductile Iron Body (ASTM A536)
- Ductile Iron Cover (ASTM A536)
- Stainless Steel Disc Guide
- Stainless Steel Seat
- Buna-N Rubber Disc
- Nylon Reinforced Buna-N Diaphragm
- Stainless Steel Stem
- Stainless Steel Spring
Typical Installation:
The upstream and downstream pressure gauges are required by Underwriters Laboratories (UL). Also a relief valve of not less than 1/2 inch in size must be installed on the downstream side of the pressure control valve. Adequate drainage for the relief valve discharge must be provided.
Standards Compliance:
ANSI/AWWA C530; AWWA C606; ANSI B1.20.1; NFPA 13; NFPA 14; NFPA 25
Features & Benefits:
- Pilot-Operated Precision Control: The Zurn 212-ZW209FPGRV maintains constant downstream pressure regardless of changing flow rates or varying inlet pressures, ensuring reliable fire protection system performance.
- Corrosion Protection: Red epoxy coating internally and externally provides FDA-approved corrosion resistance for long-term durability in fire protection applications.
- Complete Installation Package: Includes wye strainer, inlet and outlet pressure gauges with 3-way isolation valves for quick, easy installation and adjustment without additional purchases.
- UL Listed Reliability: The Wilkins 212-ZW209FPGRV meets stringent UL and C-UL safety standards for fire protection systems, providing peace of mind for critical applications.
FAQ
Q: What is the adjustable pressure range for the Wilkins 212-ZW209FPGRV?
A: The pilot control is field adjustable from 50 psi to 165 psi residual pressure, with a maximum static pressure of 175 psi.
Q: What is the minimum flow rate required to properly set this valve?
A: For the 2 1/2 inch model, the minimum flow rate to set the valve is 35 GPM, with a maximum flow rate capacity of 375 GPM.
Q: What installation orientation is recommended for this pressure reducing valve?
A: The recommended installation orientation is horizontal with the valve cover up to ensure proper air bleeding and facilitate maintenance procedures.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
"Hydrate Everyone, Everywhere!" BottleFillingStations.com | Contact us
Always consult with a licensed professional and check local codes before installation. For further details, check the Owners Manual.
