Wilkins 212-F100 | Fire Hose Valve, Angle Body Standpipe
The Wilkins 212-F100 is a 2-1/2" angle body fire hose valve designed for fire hose rack assemblies and fire department outlet connections in standpipe systems.
Key Specifications:
- Size: 2 1/2 Inches
- Maximum Inlet Pressure: 300 psi
- Notable Certifications: UL Listed, FM Approved
- Connection Type: FNPT × NH
- Flow Capacity (Cv): 148
Other Related Variants:
- 212-F100G: Grooved inlet × NH outlet
- 212-F100GST: Grooved × Special Thread outlet
- 212-F100F: FNPT inlet × FNPT outlet
- 112-F100: 1 1/2 Inches version
- 112-F100F: 1 1/2 Inches FNPT version
Materials:
- Main valve body: Brass C37700
- O-Rings: EPDM (A70)
- Handwheel: Aluminum A03600
- Handwheel Bolt: Brass C37700
- Handwheel Retaining Washer: 304 Stainless Steel
Typical Installation:
Zurn Wilkins 212-F100 Fire Hose Valves are standpipe valves listed for use on a fire hose rack assembly, or as a fire department outlet connection in commercial and industrial fire protection systems.
Standards Compliance:
UL Listed; C-UL, ULC Listed (2-1/2" only); FM Approved
Features & Benefits:
- Robust Brass Construction: C37700 brass body provides exceptional durability and corrosion resistance for long-term reliability in fire protection applications.
- High Flow Capacity: Cv 148 ensures adequate flow rates for effective fire suppression operations with minimal pressure loss.
- Versatile Connection Options: Available with FNPT, grooved, or special thread connections to accommodate various installation requirements and system configurations.
- Multiple Safety Certifications: UL Listed, FM Approved, and C-UL/ULC Listed (2-1/2") ensuring compliance with fire safety standards and building codes.
FAQ
Q: What is the maximum inlet pressure for the Zurn 212-F100 fire hose valve?
A: The maximum inlet pressure is 300 psi, making it suitable for standard standpipe system applications.
Q: What are the available outlet connection types for this valve?
A: The Wilkins 212-F100 is available with male hose (NH) outlet, FNPT outlet, or special thread outlet to match your specific fire hose or system requirements.
Q: Is the 212-F100 approved for use in Canadian installations?
A: Yes, the 2-1/2" version is C-UL and ULC Listed, making it approved for use in Canadian fire protection systems.
