Wilkins 114-F49BR | Fire Powerball Butterfly Valve, 1-1/4 Inches
NOTICE: Product images may vary from the actual item due to differences in size or configuration options.
The Wilkins 114-F49BR is a Fire Powerball butterfly sprinkler control valve engineered to provide reliable system shutoff for fire protection lines.
Key Specifications:
- Size: 1 1/4 Inches
- Maximum Working Water Pressure: 300 PSI
- Notable Certifications: UL Listed, C-UL, FM Approved
- End Connections: Threaded NPT Ends
- Operation: 1/4 Turn Anti-Water Hammer
Other Related Variants:
- 1-F49BR: 1 Inch threaded version
- 112-F49BR: 1 1/2 Inches threaded version
- 2-F49BR: 2 Inches threaded version
- 212-F49BR: 2 1/2 Inches threaded version
- 114-F49BRG: 1 1/4 Inches grooved ends version
- 112-F49BRG: 1 1/2 Inches grooved ends version
- 2-F49BRG: 2 Inches grooved ends version
- 212-F49BRG: 2 1/2 Inches grooved ends version
Materials:
- Bronze ASTM 584 C83600 main body
- 304 Stainless Steel disc
- ASTM A216 WCB handwheel
- ASTM D2000 Viton seat
- Powder Metal FD0205 95HT indicator
- Brass ASTM B16 36000 gearbox housing and cover
Typical Installation:
Fire sprinkler control systems requiring system shutoff to facilitate repair and maintenance with integrated tamper switch supervisory alarm connection for fire protection applications.
Standards Compliance:
UL Listed; C-UL; FM Approved; NFPA 13; NFPA 7; ASME B1.20.1; ANSI B36.10
Features & Benefits:
- Anti-Water Hammer Protection: Slow-closing 1/4 turn operation prevents damaging pressure surges during valve closure.
- Integrated Tamper Monitoring: Dual switch system signals valve position to alarm control panel and auxiliary equipment for comprehensive supervisory monitoring.
- Durable Construction: Bronze body with stainless steel disc and Viton seat ensures long-lasting performance in demanding fire protection applications.
- Universal Installation: Can be installed in any orientation with standard NPT threaded connections compatible with Schedule 40 and Schedule 80 pipe.
FAQ
Q: What is the purpose of the tamper switches on the Zurn 114-F49BR?
A: The tamper switches signal movement of the Zurn 114-F49BR valve from the full open position to an alarm control panel and auxiliary equipment such as indicating lights or audible alarms, providing immediate notification of unauthorized valve operation.
Q: Can the valve be installed in any pipe orientation?
A: Yes, the valve can be installed in any orientation in a piping system with standard ASME B1.20.1 NPT or standard roll or cut grooved pipe, providing maximum installation flexibility.
Q: What pipe schedules are compatible with this valve?
A: The valves are intended for use with ANSI B36.10 Schedule 40 and/or Schedule 80 pipe in sizes 1", 1-1/4", 1-1/2", 2", and 2-1/2".
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
