Zurn ZEMS6003PL-WS1-IS | AquaFlush Plus ZEMS Exposed Sensor Hardwired Diaphragm Flush Valve, Chrome
Zurn ZEMS6003PL-WS1-IS | AquaFlush Plus ZEMS Exposed Sensor Hardwired Diaphragm Flush Valve, Chrome is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Care Information
Product Care Information
- All plumbing is to be installed according to state and local codes and regulations.
- Water supply lines need to allow proper water flow for each fixture.
- Flush all lines of any debris before making connections.
- Do not use pipe sealant or plumbing grease on any fitting other then the control stop inlet.
Zurn ZEMS6003PL-WS1-IS | AquaFlush Plus ZEMS Exposed Sensor Hardwir...
The ZEMS6003PL-WS1-IS delivers hands-free flushing for urinals in commercial restrooms. Designed with AquaSense® sensor technology and a diaphragm-operated mechanism, it combines water efficiency with hygienic, touchless operation. Ideal for facilities prioritizing ADA compliance and low maintenance performance.
Key Specifications:
- Flow Rate: 1.0 gallons per flush (Low Consumption).
- Operation: Sensor-activated flush with manual override button.
- Construction: Chrome-plated brass body with chloramine-resistant internal seals.
- Dimensions: 11-1/2" overall valve height; top spud connection.
Features & Benefits:
- Touchless Operation: The integrated infrared sensor provides hygienic, hands-free flushing, reducing the spread of germs in high-traffic restrooms. A manual override button ensures functionality even during sensor recalibration or power interruptions.
- Reliable Sensor Performance: The hardwired 6VDC motorized actuator is powered by Zurn’s HW6 converter, ensuring consistent activation and long-term reliability. The sensor is factory-calibrated for standard urinal installations and can be fine-tuned for custom environments.
- Durable Build: The valve features a dezincification-resistant brass body and vandal-resistant stop cover for maximum durability. Internal seals are chloramine-resistant, extending service life in treated water systems.
What's Included:
- 1 x ZEMS6003PL-WS1-IS Exposed Urinal Flush Valve
- 1 x Sensor-Activated Actuator Assembly with Manual Override
- 1 x High Back Pressure Vacuum Breaker with One-Piece Hex Coupling Nut
- 1 x Adjustable Tailpiece
- 1 x Spud Coupling and Flange for Top Spud Connection
- 1 x Sweat Solder Kit
- 1 x Cast Wall Flange with Set Screw
- 1 x Vandal-Resistant Stop Cover
- 1 x Installation Hardware
Options Available:
- ZEMS6003PL-EWS-IS: Extra Water Saver model with 0.5 gallons per flush and hardwired sensor activation
- ZEMS6003PL-ULF-IS: Ultra Low Flow model with clog-resistant diaphragm and side-mounted motor operator
FAQ
Q: Does this valve require a specific power supply?
A: Yes. The ZEMS6003PL-WS1-IS must be powered by Zurn’s HW6 hardwire power converter or PC6 plug-in converter. Using non-Zurn power supplies may result in malfunction or damage to the sensor system.
Q: Can the sensor range be adjusted?
A: The sensor is factory-calibrated for standard urinal installations, but it can be manually recalibrated using the override button and a target. This allows customization based on stall layout or reflective surfaces.
Detailed Features & Benefits
Advanced Sensor Technology: The infrared convergence-type sensor detects users reliably and initiates flushing only after proper use. This minimizes ghost activations and ensures water is used efficiently.
Hardwired Power System: The valve is powered by Zurn’s HW6 converter, delivering regulated 6VDC for consistent sensor performance. It supports up to eight valves per unit, simplifying electrical planning for multi-fixture installations.
Commercial-Grade Durability: Built with a chrome-plated brass body and reinforced internal components, the valve withstands heavy use and resists corrosion. The vandal-resistant stop cover and cast wall flange add extra protection in public settings.
NOTICE: All products come with a limited three-year warranty on materials and workmanship when properly installed and maintained. Decorative finishes warranted for one year.
