Zurn ZER6003AV-CPM | Exposed Sensor Operated Battery Powered Flush Valve for 3/4" Urinals
Zurn ZER6003AV-CPM | Exposed Sensor Operated Battery Powered Flush Valve for 3/4" Urinals - Standard is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Care Information
Product Care Information
- All plumbing is to be installed according to state and local codes and regulations.
- Water supply lines need to allow proper water flow for each fixture.
- Flush all lines of any debris before making connections.
- Do not use pipe sealant or plumbing grease on any fitting other then the control stop inlet.
The ZER6003AV-CPM delivers reliable sensor-operated performance with exceptional water conservation for urinals in commercial restrooms. Its battery-powered operation combines with Zurn's AquaVantage technology for dependable hands-free flushing that maximizes hygiene and minimizes maintenance.
Key Specifications:
- Operation: Sensor activated with 6VDC motor actuator and battery power.
- Construction: Chrome-plated brass with polished exterior and vandal-resistant features.
- Technology: Chloramine resistant, dual seal AquaVantage TPE diaphragm with clog-resistant by-pass.
- Compliance: ADA compliant and meets ASSE 1037/ASME A112.1037/CSA B125.37 standards.
Features & Benefits:
- Hands-Free Operation: The infrared convergence-type proximity sensor eliminates the need for physical contact, improving restroom hygiene.
- Manual Override: Includes a manual sensor with capacitive sensing push button for emergency operation when needed.
- Vandal Protection: Control stop has internal siphon-guard protection and vandal resistant stop cap for high-traffic installations.
- Versatile Installation: Includes adjustable tailpiece, spud coupling, and flange for top spud connection to fit a variety of fixture configurations.
- Durable Design: Constructed from proprietary dezincification-resistant low lead brass alloy for extended service life in aggressive water conditions.
Options Available:
- ZER6003AV-ULF-CPM: Ultra Low Flow model at 0.125 gallons per flush for maximum water conservation with WaterSense certification.
- ZER6003AV-EWS-CPM: Extra Water Saver model at 0.5 gallons per flush for balanced water efficiency with WaterSense certification.
- ZER6003AV-WS1-CPM: Water Saver model at 1.0 gallon per flush for standard efficiency applications.
What's Included:
- 1 x ZER6003AV-CPM Sensor Operated Battery Powered Urinal Flush Valve
- 1 x AquaVantage TPE Diaphragm
- 1 x High Back Pressure Vacuum Breaker
- 1 x Adjustable Tailpiece
- 1 x Spud Coupling and Flange for Top Spud Connection
- 1 x Sweat Solder Kit with Cast Wall Flange
- 1 x Vandal Resistant Stop Cap
- 1 x Installation Hardware
- 1 x Battery Compartment with Batteries
FAQ
Q: What is the battery life for this flush valve?
A: The ZER6003AV-CPM is designed for long-term operation with standard C-cell batteries. Under normal usage conditions in commercial settings, the battery pack typically provides multiple years of reliable service. A convenient battery indicator LED flashes red when batteries need replacement, ensuring you can proactively maintain the system without unexpected downtime.
Q: Can this flush valve be adjusted after installation?
A: Yes, the ZER6003AV-CPM features adjustable sensor range settings. The unit comes preset from the factory, but the activation distance can be easily modified using the included sensor adjustment tool if special circumstances require customization. This allows for optimal performance in various restroom layouts and prevents false activations from stall doors or highly reflective surfaces.
Detailed Features & Benefits
Advanced Sensor Technology: The ZER6003AV-CPM utilizes an integral infrared convergence-type proximity sensor with a 10-degree angled sensor for optimal user detection. The system includes a 5-second delay to prevent unnecessary flushes when someone briefly walks by, and a visual indicator system with LED lights provides feedback on system status. A courtesy manual flush button allows for activation when needed, making it ideal for all commercial applications.
Water-Efficient Operation: Available in multiple flow rate options to meet specific water conservation goals, the ZER6003AV-CPM helps facilities reduce water consumption while maintaining excellent performance. The clog-resistant by-pass in the AquaVantage TPE diaphragm ensures consistent water delivery with each flush, while the high back pressure vacuum breaker with one-piece hex coupling nut prevents backflow contamination.
Robust Construction: Built to withstand the demands of high-traffic commercial environments, the ZER6003AV-CPM features a chrome-plated brass body with a polished exterior and impact-resistant polycarbonate housing. The unit operates effectively with water pressure from 20 to 80 psi (138 to 552 kPa), providing reliable performance across a wide range of installation conditions.
NOTICE: All products come with a limited three-year warranty on materials and workmanship when properly installed and maintained according to instructions. Decorative finishes warranted for one year.
