Hoshizaki KM-660MAJ | KMEdgeX Undercounter Crescent Cuber Ice Machine, Air-cooled
Hoshizaki KM-660MAJ | KMEdgeX Undercounter Crescent Cuber Ice Machine, Air-cooled is backordered and will ship as soon as it is back in stock.
Product Care Information
Product Care Information
Installation
This icemaker must be installed in accordance with applicable national, state, and local codes and regulations. Do not install the icemaker in a corner where the door will interfere with other equipment or where the icemaker cannot be pulled out for service.
Maintenance
Clean and sanitize this icemaker at least once a year. In certain water conditions, more frequent cleaning and sanitizing may be necessary.
Hoshizaki KM-660MAJ | KMEdgeX Undercounter Crescent Cuber Ice Machi...
The KM-660MAJ by Hoshizaki is a high-capacity, air-cooled modular crescent cuber designed for commercial use in large-scale operations. This powerful ice machine combines impressive ice production of up to 669 lbs per day with innovative features like CycleSaver™ design and EverCheck™ alert system. Its durable stainless steel construction, space-efficient design, and advanced self-diagnostic programming make it an ideal choice for hotels, restaurants, and healthcare facilities requiring consistent, high-volume ice production.
Key Specifications:
- Ice Production Capacity: Up to 669 lbs of crescent ice per 24 hours at 70°F air/50°F water; 560 lbs at 90°F air/70°F water.
- Dimensions: 22" W x 27⅜" D x 28" H, slim-line design suitable for commercial spaces.
- Electrical: Operates on 115V/60/1 with a maximum fuse size of 20A, drawing 15.2A under normal conditions.
- Refrigerant: Uses R-404A with a charge amount of 1 lb 9.8 oz.
- Water Usage: 14.8 gallons per 100 lbs of ice produced at 90°F air/70°F water.
Features & Benefits:
- CycleSaver™ Design: Reduces harvest cycles, increasing efficiency and lowering component wear.
- EverCheck™ Alert System: Provides real-time diagnostics and alerts for proactive maintenance.
- H-GUARD Plus Antimicrobial Agent: Protects against bacterial growth for cleaner, safer ice.
- Stainless Steel Double-Sided Evaporator: Ensures durability and consistent ice production.
- Energy Efficiency: Consumes only 5.3 kWh per 100 lbs of ice, balancing high output with energy conservation.
What's Included:
- KM-660MAJ Modular Crescent Cuber unit
- Removable air filters (air-cooled model)
- Factory-installed ultrasonic bin control
- Installation and operation manual
- Warranty documentation
Options Available:
- KM-660MAJ-E: Air-cooled modular crescent cuber designed for 50Hz electrical systems, ideal for international installations requiring high-volume ice production.
- KM-660MWJ: Water-cooled modular crescent cuber with up to 669 lbs of ice production per day, engineered for facilities with reliable water supply and efficient cooling needs.
- KM-660MRJZ: Remote-cooled modular crescent cuber paired with the URC-5FZ condenser, offering up to 642 lbs of ice production per day with reduced heat output in the installation area.
FAQ
Q: What are the plumbing requirements for the KM-660MAJ?
A: The KM-660MAJ requires a minimum 3/8" Nominal ID Copper Water Tubing or equivalent for the icemaker water supply line. For drainage, it needs a minimum 3/4" Nominal ID Hard Pipe or equivalent. The unit operates with a water pressure range of 10-113 PSIG and a water temperature range of 45°F to 90°F.
Q: Is this ice machine compatible with different types of ice storage bins?
A: Yes. The KM-660MAJ is compatible with Hoshizaki bins including B-300SF, B-500SF, B-700SF, and larger capacity bins like B-1150SS and B-1300SS. A top kit may be required for certain bin models.
Q: What is the warranty coverage for this ice machine?
A: Hoshizaki provides a 3-year parts and labor warranty on the entire machine, a 5-year parts and labor warranty on the evaporator, and a 5-year parts warranty on the compressor and air-cooled condenser coil. Valid in the U.S., Canada, Puerto Rico, and U.S. Territories.
Detailed Features & Benefits
High-Volume Production and Energy Efficiency: Produces up to 669 lbs of ice per day, making it ideal for hotels, convention centers, and high-volume restaurants. Despite its high output, it consumes only 5.3 kWh per 100 lbs of ice, reducing operational costs and supporting sustainability goals.
CycleSaver™ Technology and Durability: Reduces the number of freeze/harvest cycles required, lowering energy use and component wear. The stainless steel double-sided evaporator enhances durability and efficiency, while the EverCheck™ alert system provides real-time diagnostics for proactive maintenance.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
