Elkay LVRC8S | Wall-mount VRC-style Drinking Fountain | Filtered, Refrigerated, Fully Vandal-resistant
Elkay LVRC8S | Wall-mount VRC-style Drinking Fountain | Filtered, Refrigerated, Fully Vandal-resistant is backordered and will ship as soon as it is back in stock.
Product Care Information
Product Care Information
Installation
- Elkay & Halsey Taylor Bottle Filling Stations require installation from a licensed plumber. Email us at support@bottlefillingstations.com, and we can see if our network of service professionals cover your area.
- Requires access to electrical connection.
- Product also includes physical copy of installation instructions in package.
ezH2O Installation Video:
Maintenance
It is recommended to routinely clean your Bottle Filling Station with a soft cloth and mild dishwashing soap to spray and wipe down the unit. It is also recommended to clean the flexible fill mat. Remove the four screws to wipe beneath and on top of the mat.
ezH2O Maintenance Video:Filter Replacement
When filter status light turns to red, the filter needs to be changed. Here are some detailed instructions.
ezH20 Filter Change Video:
Elkay LVRC8S | Wall-mount VRC-style Drinking Fountain | Filtered, R...
The Elkay LVRC8S is a Wall Mount Vandal-Resistant ADA Cooler, filtered and refrigerated, delivering 8.0 GPH of chilled water. Finished in Stainless Steel, this unit combines mechanical activation, vandal-resistant construction, ADA accessibility, and reliable filtration for schools, parks, offices, and public facilities.
Key Specifications:
- Design: Wall-mounted ADA cooler with vandal-resistant bubbler and mechanical front pushbutton activation.
- Finish: Stainless Steel.
- Filtration: Includes 51299C WaterSentry® Filter, 1,500–3,000 gallon capacity or 1 year.
- Refrigeration: 8.0 GPH of 50°F drinking water (based on 80°F inlet and 90°F ambient). Uses R-134a refrigerant.
- Stations Served: 1.
Features & Benefits:
- Filtered Hydration: NSF/ANSI-certified filter reduces lead, microplastics, particulates, cysts, and chlorine taste/odor.
- Vandal Resistance: Heavy-duty bubbler and reinforced stainless steel panels withstand tampering and abuse.
- Mechanical Reliability: Pushbutton activation ensures water delivery even during electrical service interruptions.
- ADA Compliant: Barrier-free design meets ADA & ICC A117.1 accessibility standards.
- Indoor + Outdoor Ready: Suitable for outdoor use when properly winterized or protected from extreme climates.
What's Included:
- LVRC8S vandal-resistant ADA cooler unit
- Standard 51299C WaterSentry® filter
- Installation hardware
- Owner’s manual and warranty guide
FAQ
Q: Does the LVRC8S include filtration?
A: Yes. The LVRC8S includes the 51299C WaterSentry® Filter, rated for 1,500–3,000 gallons or 1 year.
Q: What warranty is included?
A: Elkay provides a 5-year limited warranty on the refrigeration system and a 12-month warranty on electrical components and the water system.
Q: Can this unit be installed outdoors?
A: Yes. The LVRC8S is suitable for outdoor use when properly winterized or protected from extreme heat.
Q: Are accessories available?
A: Yes. Optional accessories include the MLP100 In-Wall Carrier for secure installation, the 98324C Cane Apron for ADA compliance, and the 97446C Vandal-Resistant Bubbler Kit.
Detailed Features & Benefits
Cooling System: Hermetically-sealed reciprocating compressor with lifetime lubrication, fan-cooled condenser, and copper tubing fully insulated with EPS foam. Uses R-134a refrigerant metered by capillary tube. Factory-preset thermostat requires minimal adjustment.
Vandal-Resistant Design: Reinforced stainless steel panels, tamper-resistant fastenings, and heavy-duty bubbler withstand abuse in public spaces.
Mechanical Reliability: Mechanical pushbutton activation guarantees water delivery even during electrical service interruptions.
ADA Accessibility: Barrier-free design meets ADA & ICC A117.1 standards. Compatible with the 98324C Cane Apron for enhanced compliance.
Outdoor Durability: Suitable for outdoor installations when properly winterized or protected from extreme climates.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
