Wilkins 212-500XL3 | 2 1/2" Pressure Reducing Valve
NOTICE: Product images may vary from the actual item due to differences in size or configuration options.
The Wilkins 212-500XL3 is a 2 1/2 inch high-flow pressure reducing valve engineered for commercial and industrial potable water systems, delivering stable downstream pressure control with superior flow performance.
Key Specifications:
- Size: 2 1/2 Inches
- Maximum Working Water Pressure: 400 PSI
- Maximum Working Water Temperature: 140°F
- Notable Certifications: ASSE 1003, cUPC, CSA B356
- Threaded connections (FNPT): ANSI B1.20.1
Other Related Variants:
- 112-500XL3: 1 1/2 Inches version
- 114-500XL3: 1 1/4 Inches version
- 1-500XL3: 1 Inch version
- 2-500XL3: 2 Inches version
- 3-500XL3: 3 Inches version
Materials:
- Low lead cast bronze body ASTM B806
- Cast bronze bell housing ASTM B584
- Stainless steel fasteners, 300 series
- Stainless steel stem, 300 series
- Low lead cast bronze plunger ASTM B806
- Buna Nitrile elastomers, FDA approved
- EPDM elastomers, FDA approved
- Chrome silicon springs, epoxy coated
- Noryl cartridge
Typical Installation:
Commercial plumbing systems and industrial water lines requiring high inlet pressure reduction to lower outlet pressure. Suitable for outdoor installation with protective enclosure, vertical or horizontal mounting positions. Can be installed with optional backflow preventers, strainers, and shut-off valves for complete system protection.
Standards Compliance:
ASSE Listed 1003; cUPC Listed; CSA Certified B356; NSF/ANSI/CAN 61; NSF/ANSI/CAN 372
Features & Benefits:
- Balanced Piston Design: Provides smooth, responsive pressure regulation and protection from inlet pressure changes while maintaining stable downstream pressure.
- Integral Venturi Technology: Patented design delivers best-in-class flow performance for high-demand commercial and industrial applications.
- Removable Cartridge: Corrosion-resistant internal components allow for easy maintenance without removing the valve body from the line.
- Adjustable Pressure Range: Outlet pressure adjustable from 15 to 75 PSI with factory preset at 50 PSI to meet varying system requirements.
FAQ
Q: What is the recommended installation position for the Zurn 212-500XL3?
A: The Wilkins 212-500XL3 may be installed in any position—horizontal or vertical—providing flexibility for various piping configurations in commercial and industrial settings.
Q: When should multiple pressure reducing valves be installed in series?
A: Multiple installations in series are required when the desired pressure reduction is more than 3 to 1 ratio (e.g., 150 PSI inlet reduced to 50 PSI outlet). A low flow bypass may be needed for flows under 10 GPM at higher reduction ratios.
Q: What certifications does the Zurn 212-500XL3 carry?
A: The valve is ASSE Listed 1003, cUPC Listed, CSA Certified B356, and meets NSF/ANSI/CAN 61 & 372 requirements for safe use in potable water systems.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
