Elkay LK4420 | Outdoor Drinking Fountain, Double-station, Freestanding
The Elkay LK4420 Outdoor Bi-Level Pedestal Fountain provides durable, vandal-resistant hydration for parks, campuses, recreational facilities, and other outdoor environments. Featuring heavy-duty 300 Series stainless steel construction, mechanical activation, and a bi-level ADA-compliant design, it delivers reliable drinking water access without requiring electrical service.
Key Specifications:
| Design | Outdoor bi-level pedestal drinking fountain with vandal-resistant bubbler and mechanical activation |
| Finish | Evergreen (EVG), Black (BLK), Blue (BLU), or Gray (GRY) |
| Filtration | Non-filtered; contact us for guidance regarding compatible inline filtration solutions |
| Refrigeration | Non-refrigerated; may be paired with a remote chiller in properly protected installations |
| Stations Served | 2 drinking fountains |
Features & Benefits:
- Heavy-Duty Vandal Resistance: 300 Series stainless steel construction helps withstand demanding outdoor environments.
- Mechanical Activation: Continues providing water without requiring electrical power.
- Laminar Flow Technology: Produces a smooth water stream with minimal splash.
- ADA-Compliant Design: Bi-level fountain configuration improves accessibility for a wide range of users.
- Outdoor Performance: Freestanding pedestal design is engineered for year-round outdoor installation.
Color Options:
- LK4420EVG: Evergreen
- LK4420BLK: Black
- LK4420BLU: Blue
- LK4420GRY: Gray
- LK4420PUR: Brown, Orange, Purple, Red, Terracotta, White, Yellow, and Beige available by special order.
What's Included:
- Elkay LK4420 Outdoor Bi-Level Pedestal Fountain
- Pre-installed Vandal-Resistant Bubbler
- Push Button Activation Assembly
- Access Panel (8" x 10")
- Removable Bottom Cover
- Drain Adapter Kit
- Drain Elbow Kit
- Tailpipe and Drain Tubes
- Poly Tubing
- In-Line Strainer
- Installation Instructions and Owner's Manual
*Fasteners, service stop valve, and waste trap are not included and must be supplied by the installer according to local code requirements.
FAQ
Q: What Color Options Are Available for the Elkay LK4420 Outdoor Bi-Level Pedestal Fountain?
A: Standard color options include Evergreen (EVG), Black (BLK), Blue (BLU), and Gray (GRY). Additional colors including Beige, Brown, Orange, Purple, Red, Terracotta, White, and Yellow are available for qualifying orders.
Q: Is the Elkay LK4420 Outdoor Bi-Level Pedestal Fountain ADA Compliant?
A: Yes. The Elkay LK4420 complies with ADA and ICC A117.1 accessibility requirements when installed according to applicable standards.
Q: Is the Elkay LK4420 Outdoor Bi-Level Pedestal Fountain Filtered?
A: No. The LK4420 is a non-filtered drinking fountain. Contact BottleFillingStations.com for assistance selecting compatible inline filtration options.
Q: Is the Elkay LK4420 Outdoor Bi-Level Pedestal Fountain Refrigerated?
A: No. The LK4420 is a non-refrigerated fountain. In certain applications, a remote chiller may be added to provide chilled water.
Q: Does the Elkay LK4420 Outdoor Bi-Level Pedestal Fountain Require Electricity?
A: No. The mechanically activated design operates without electrical power, making it suitable for many outdoor installations.
Q: What Accessories Are Available for the Elkay LK4420 Outdoor Bi-Level Pedestal Fountain?
A: Optional accessories include the LK4471LHB Locking Hose Bib and the 97890C Direct Bury Adaptor.
Q: What Water Pressure Is Recommended for the Elkay LK4420 Outdoor Bi-Level Pedestal Fountain?
A: The installation manual specifies a supply pressure range of 20 to 105 PSI for proper operation.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
"Hydrate Everyone, Everywhere!" BottleFillingStations.com | Contact us now
The Elkay LK4420 is a heavy‑duty outdoor drinking fountain designed for parks, schools, recreational facilities, and other public spaces. Constructed for durability and vandal resistance, it provides reliable hydration in outdoor environments while maintaining accessibility and long‑term performance.
Key Installation Requirements:
- Outdoor pedestal installation on a stable concrete foundation
- Cold water supply connection required
- Drain connection required for proper operation
- Anchoring hardware must be securely fastened to mounting surface
- Allow service access to internal plumbing components
- Follow local plumbing codes and accessibility requirements during installation
Important Notes Before Installing:
- Always shut off water supply before performing installation or maintenance
- Ensure foundation is level before securing the fountain
- Do not overtighten plumbing fittings or mounting hardware
- Verify proper drainage to prevent standing water around the installation area
- Outdoor installations in freezing climates may require seasonal winterization procedures
- Inspect all water and drain connections for leaks before placing unit into service
Basic Installation Overview:
- Prepare concrete pad and verify mounting location requirements
- Position fountain and secure pedestal to foundation
- Connect water supply line to fountain inlet connection
- Connect waste line to building or site drainage system
- Pressurize water system and inspect for leaks
- Adjust water stream for proper operation if necessary
- Secure access panels and complete final inspection
For complete specifications and installation guidelines, download the official LK4420 Spec Sheet and the Installation Manual.
