Wilkins 8-FSC | Ductile Iron Y-Type Strainer | 8 Inches Flanged
The Wilkins 8-FSC is an 8 Inches ductile iron Y-type strainer built to protect water line equipment from sediment and debris.
Key Specifications:
- Size: 8 Inches
- Pressure Rating: 200 psi WOG; 125 psi Steam
- Temperature Rating: 150°F WOG; 450°F Steam
- Notable Certifications: MIL-S-16293F Type 2; NSF/ANSI/CAN 372
- End Connections: ASME B16.42 Class 150 Flanged
Other Related Variants:
- 212-FSC: 2 1/2 Inches version
- 3-FSC: 3 Inches version
- 4-FSC: 4 Inches version
- 6-FSC: 6 Inches version
- 10-FSC: 10 Inches version
- 12-FSC: 12 Inches version
Materials:
- Main Valve Body: Ductile Iron ASTM A536
- Access Cover: Ductile Iron ASTM A536
- Coating: Fusion Epoxy Finish (NSF/ANSI/CAN 61 compliant) inside and out
- Screen: Perforated 300 Series Stainless Steel
Typical Installation:
Local codes shall govern installation requirements. Unless otherwise specified, the assembly shall be mounted with sufficient clearance for maintenance in accordance with the manufacturers' instructions and the latest edition of the Uniform Plumbing Code. The installation shall be made so that no part of the unit can be submerged. Horizontal installation with the strainer cap facing downward is the preferred installation orientation; however the Zurn 8-FSC strainer will provide protection in any orientation. Suitable for both outdoor and indoor installations.
Standards Compliance:
MIL-S-16293F Type 2; NSF/ANSI/CAN 372 (Lead Free); NSF/ANSI/CAN 61 (Fusion Epoxy Coating)
Features & Benefits:
- Robust Construction: Ductile iron ASTM A536 body and access cover provide long-lasting durability in demanding water line applications.
- NSF-Compliant Coating: Fusion Epoxy Finish applied inside and out meets NSF/ANSI/CAN 61 requirements, ensuring safe use in potable water systems.
- Easy Maintenance: The integral strainer screen on the Zurn 8-FSC is accessible for cleaning without removing the device from the line, minimizing downtime.
- Flexible Installation: Functions in any orientation, with horizontal cap-down being preferred, making it adaptable for various piping configurations.
FAQ
Q: Can the Wilkins 8-FSC be installed in any orientation?
A: Yes. While horizontal installation with the strainer cap facing downward is preferred, the strainer will provide protection in any orientation.
Q: What is the flow capacity of the 8-FSC at standard flow velocities?
A: Through Schedule 40 pipe, the 8 Inches model flows 780 GPM at 5 ft/sec, 1,169 GPM at 7.5 ft/sec, 1,559 GPM at 10 ft/sec, and 2,339 GPM at 15 ft/sec.
Q: Can the screen be cleaned without removing the strainer from the line?
A: Yes. The integral strainer screen is designed to be accessible for cleaning without removing the device from the pipeline, simplifying routine maintenance.
NOTICE: Do not use with water that is unsafe or of unknown quality without adequate disinfection either before or after the system.
